Application

Application

MIL-STD-348B U.S. Military Connector

READ MORE

MIL-STD-348B:DEPARTMENT OF DEFENSE INTERFACE STANDARD is the most comprehensive RF/Microwave connector available.

It contains the reference dimensions for RF connectors meeting US military specifications.

Also, this standard specifies the dimensional requirements for radio frequency connector interfaces referenced in MIL-DTL-3643, MIL-DTL-3650, MIL-STD-3655, MIL-DTL-25516, MIL-PRF-31031, MIL-PRF-39012, MIL-PRF-49142, MIL-PRF-55339 and MIL-DTL-83517.

MIL-STD-348B U.S. Military Connector

Anti-Vibration

Harsh Environment

READ MORE

Chin Nan anti-vibration connectors advanced the design of standard push-on RF/Microwave connector by adding a screwing mechanism to prevent the accidental disconnection.

Vibration available to mil-std-202, method 204, condition G.

Anti-Vibration

Waterproof & Hermetically Sealed

Harsh Environment

READ MORE

Chin Nan sealed connectors are provided with waterproof protection of environmentally.
The sealed connector is rated to IP68 criteria and can be submerged to shallow depths. Also, prevent the ingress water, moisture, gasoline and other chemical.


Chin Nan hermetic connectors are designed for use in harsh application environments. The sealing (helium leak) rate for our hermetic connectors can achieved to 1X10-8 cc/sec.

Waterproof & Hermetically Sealed

mmWave Connector

READ MORE

Military, Aerospace and Commercial which require millimeter wave frequency range with low loss performance.

Millimetre wave connectors are designed for use in 50 ohm systems, and operate in the frequency ranges up to 110GHz (dependant upon series).

The connectors are designed to have a low VSWR and return loss.

mmWave Connector

Board To Board Connector

READ MORE

Board to Board Connector applied frequency up to 65 GHz.

Chin Nan RPSMP connectors are designed to combine the minimum board-to-board space of SMP connectors with the high power ratings of SMA connectors. These RPSMP non-standard interface connectors have an operating frequency range of up to 65 GHz.

Board To Board Connector

Low Interference: Low PIM

LTE & 5G/6G

READ MORE

Low PIM connectors are designed for high frequency, low-intermodulation and low return loss, suitable for outdoor applications.
These low loss 50ohm connectors are now widely used in wireless, wifi and GSM base station.

Low Interference: Low PIM

Low Interference: Non-magnetic

Medical

READ MORE

Non-magnetic coaxial connectors are used primarily inside MRI medical equipment.
Magnetic Resonance Imaging is an advanced imaging technique that is able to produce high resolution cross-sectional images for inside human body by exploiting Radio Frequency (RF) pulses.

Non-magnetic coaxial connectors allow placement in or near the imaging area in advanced medical imagin equipment.

Low Interference: Non-magnetic

RF Switch Connector

READ MORE

RF switching connector provides a unique means of switching between two RF signal paths.
As user friendly as a standard connector, the switch is mechanically activated by mating and un-mating the connector.
This connector lets antenna switches a connection either internally or externally.

RF Switch Connector

Blind Mate

READ MORE

Blind mate connectors are used in which the mating action happens where equipment must slide in and make connections inside the cabinet.

Blind Mate

4K/8K UHD-SDI

READ MORE

High Speed High Definition Video Applications such as 4K ULTRA HD TV and CoaXPress (CXP).

Chin Nan launched a new range of 75 ohm connectors which operate at the increased bandwidth and frequencies required for UHD Serial Digital Video environments. They are provided superior VSWR, impendance and return loss through 6 GHz.

4K/8K UHD-SDI
